Description
The new large-coverage fragrance diffuser series, the black technology magnetic lock protects essential oils from theft, the new high-efficiency silent plug-in atomizer head, and the fragrance diffusion effect are upgraded again: stable mist volume, tiny particles. With a high-speed fan to achieve rapid fragrance diffusion, quick-connect touch control interface. Multiple ways of use: can be placed independently, connected to the HAVC system, one machine for multiple uses, suitable for different scenarios. It uses a cutting-edge diaphragm air pump, which is silent and durable, with a lifespan of more than 20,000 hours, suitable for hotels, airports, office buildings, cinemas, shopping malls, entertainment clubs and other places.
Warranty: 12 months
Technical Specs
Bottle capacity: 1000ml
Power/Voltage: DC 12V /15W
Coverage: 4000 cubic meter
Dimension: W141mm*D141mm*H553mm
Bottle capacity: 1000ml
Noise level: ≤ 34dBa
Net weight: 4.29 KG
Installation method: HVAC Connect / Stand-alone
Suitable for: Hotel reception/Theatre Hall/Pavilion/Restaurant etc.
Diffusing Times
Working time: 1 hour, 2 hours, 4 hours, 8 hours
10 seconds aroma diffusion with 300 seconds pause (oil consumption: 0.06 ml / h diffusion)
30 seconds aroma diffusion with 300 seconds pause (oil consumption: 0.17 ml / h diffusion)
100 seconds aroma diffusion with 300 seconds pause (oil consumption: 0.46 ml / h diffusion)
60 seconds aroma diffusion with 120 seconds pause (oil consumption: 0.61 ml / h diffusion)
90 seconds aroma diffusion with 120 seconds pause (oil consumption: 0.78 ml / h diffusion)
150 seconds aroma diffusion with 120 seconds pause (oil consumption: 1.02 ml / h diffusion)
150 seconds aroma diffusion with 60 seconds pause (oil consumption: 1.31 ml / h diffusion)
300 seconds aroma diffusion with 60 seconds pause (oil consumption: 1.53 ml / h diffusion)
300 seconds aroma diffusion with 10 seconds pause (oil consumption: 1.77 ml / h diffusion)
Maintenance
To ensure the best diffusing effect, please check and clean the device every six months.
Please clean the device when you wish to replace the perfume oil or the diffusing effect will be weakened.
Maintenance steps:
1. Unlock the door and take out oil canister which is spent.
2. Fill some alcohol into the canister and clean it.
3. Install the canister on the device filling with alcohol and
make the device stay in working status for 5-10 minutes.
4. Turn off the power when finishing cleaning.
5. Take out the canister and fill fragrance oil into it again and install on the device, then lock the cover to finish the maintenance process.
